NASA says Orion’s heat shield is good to go for Artemis II—but does it matter?

artemis, artemis II, bill nelson, human spaceflight, moon, NASA, orion, space launch system, Uncategorized / /

“We have since determined that while the capsule was dipping in and out of the atmosphere, as part of that planned skip entry, heat accumulated inside the heat shield outer layer, leading to gases forming and becoming trapped inside the heat shield,” said Pam Melroy, NASA’s deputy administrator. “This caused internal pressure to build up and led to cracking and uneven shedding of that outer layer.”

An independent team of experts concurred with NASA’s determination of the root cause, Melroy said.

NASA Administrator Bill Nelson, Deputy Administrator Pam Melroy, Associate Administrator Jim Free, and Artemis II Commander Reid Wiseman speak with reporters Thursday in Washington, DC. Credit: NASA/Bill Ingalls

Counterintuitively, this means NASA engineers are comfortable with the safety of the heat shield if the Orion spacecraft reenters the atmosphere at a slightly steeper angle than it did on Artemis I and spends more time subjected to higher temperatures.

When the Orion spacecraft climbed back out of the atmosphere during the Artemis I skip reentry, a period known as the skip dwell, NASA said heating rates decreased and thermal energy accumulated inside the heat shield’s Avcoat material. This generated gases inside the heat shield through a process known as pyrolysis.

“Pyrolysis is just burning without oxygen,” said Amit Kshatriya, deputy associate administrator of NASA’s Moon to Mars program. “We learned that as part of that reaction, the permeability of the Avcoat material is essential.”

During the skip dwell, “the production of those gases was higher than the permeability could tolerate, so as a result, pressure differential was created. That pressure led to cracks in plane with the outer mold line of the vehicle,” Kshatriya said.

NASA didn’t know this could happen because engineers tested the heat shield on the ground at higher temperatures than the Orion spacecraft encountered in flight to prove the thermal barrier could withstand the most extreme possible heating during reentry.

“What we missed was this critical region in the middle, and we missed that region because we didn’t have the test facilities to produce the low-level energies that occur during skip and dwell,” Kshatriya said Thursday.

During the investigation, NASA replicated the charring and cracking after engineers devised a test procedure to expose Avcoat heat shield material to the actual conditions of the Artemis I reentry.

So, for Artemis II, NASA plans to modify the reentry trajectory to reduce the skip reentry’s dwell time. Let’s include some numbers to help illustrate the difference.

The distance traveled by Artemis I during the reentry phase of the mission was more than 3,000 nautical miles (3,452 miles; 5,556 kilometers), according to Kshatriya. This downrange distance will be limited to no more than 1,775 nautical miles (2,042 miles; 3,287 kilometers) on Artemis II, effectively reducing the dwell time the Orion spacecraft spends in the lower heating regime that led to the cracking on Artemis I.

NASA’s inspector general report in May included new images of Orion’s heat shield that the agency did not initially release after the Artemis I mission. Credit: NASA Inspector General

With this change, Kshatriya said NASA engineers don’t expect to see the heat shield erosion they saw on Artemis I. “The gas generation that occurs during that skip dwell is sufficiently low that the environment for crack generation is not going to overwhelm the structural integrity of the char layer.”

For future Orion spaceships, NASA and its Orion prime contractor, Lockheed Martin, will incorporate changes to address the heat shield’s permeability problem.

Waiting for what?

NASA officials discussed the heat shield issue, and broader plans for the Artemis program, in a press conference in Washington on Thursday. But the event’s timing added a coat of incredulity to much of what they said. President-elect Donald Trump, with SpaceX founder Elon Musk in his ear, has vowed to cut wasteful government spending.

NASA says Orion’s heat shield is good to go for Artemis II—but does it matter? Read More »

nasa-is-stacking-the-artemis-ii-rocket,-implying-a-simple-heat-shield-fix

NASA is stacking the Artemis II rocket, implying a simple heat shield fix

artemis, artemis II, human spaceflight, Kennedy Space Center, NASA, orion, Science, Space, space launch system, vehicle assembly building / /

A good sign

The readiness of the Orion crew capsule, where the four Artemis II astronauts will live during their voyage around the Moon, is driving NASA’s schedule for the mission. Officially, Artemis II is projected to launch in September of next year, but there’s little chance of meeting that schedule.

At the beginning of this year, NASA officials ruled out any opportunity to launch Artemis II in 2024 due to several technical issues with the Orion spacecraft. Several of these issues are now resolved, but NASA has not released any meaningful updates on the most significant problem.

This problem involves the Orion spacecraft’s heat shield. During atmospheric reentry at the end of the uncrewed Artemis I test flight in 2022, the Orion capsule’s heat shield eroded and cracked in unexpected ways, prompting investigations by NASA engineers and an independent panel.

NASA’s Orion heat shield inquiry ran for nearly two years. The investigation has wrapped up, two NASA officials said last month, but they declined to discuss any details of the root cause of the heat shield issue or the actions required to resolve the problem on Artemis II.

These corrective options ranged from doing nothing to changing the Orion spacecraft’s reentry angle to mitigate heating or physically modifying the Artemis II heat shield. In the latter scenario, NASA would have to disassemble the Orion spacecraft, which is already put together and is undergoing environmental testing at Kennedy Space Center. This would likely delay the Artemis II launch by a couple of years.

In August, NASA’s top human exploration official told Ars that the agency would hold off on stacking the SLS rocket until engineers had a good handle on the heat shield problem. There are limits to how long the solid rocket boosters can remain stacked vertically. The joints connecting each segment of the rocket motors are certified for one year. This clock doesn’t actually start ticking until NASA stacks the next booster segments on top of the lowermost segments.

However, NASA waived this rule on Artemis I when the boosters were stacked nearly two years before the successful launch.

A NASA spokesperson told Ars on Wednesday that the agency had nothing new to share on the Orion heat shield or what changes, if any, are required for the Artemis II mission. This information should be released before the end of the year, she said. At the same time, NASA could announce a new target launch date for Artemis II at the end of 2025, or more likely in 2026.

But because NASA gave the “go” for SLS stacking now, it seems safe to rule out any major hardware changes on the Orion heat shield for Artemis II.

NASA is stacking the Artemis II rocket, implying a simple heat shield fix Read More »

it’s-increasingly-unlikely-that-humans-will-fly-around-the-moon-next-year

It’s increasingly unlikely that humans will fly around the Moon next year

artemis II, ground systems, orion, Science, Space / /

Don’t book your tickets for the launch of NASA’s Artemis II mission next year just yet.

We have had reason to doubt the official September 2025 launch date for the mission, the first crewed flight into deep space in more than five decades, for a while now. This is principally because NASA is continuing to mull the implications of damage to the Orion spacecraft’s heat shield from the Artemis I mission nearly two years ago.

However, it turns out that there are now other problems with holding to this date as well.

No schedule margin

A new report from the US Government Accountability Office found that NASA’s Exploration Ground Systems program—this is, essentially, the office at Kennedy Space Center in Florida responsible for building ground infrastructure to support the Space Launch System rocket and Orion—is in danger of missing its schedule for Artemis II.

During this flight a crew of four astronauts, commanded by NASA’s Reid Wiseman, will launch inside Orion on a 10-day mission out to the Moon and back. The spacecraft will follow a free-return trajectory, which is important, because if there is a significant problem with Orion spacecraft’s propulsion system, the trajectory of the vehicle will still carry it back to Earth. At their closest approach, the crew will come within about 6,500 miles (10,400 km) of the surface of the far side of the Moon.

The new report, published Thursday, finds that the Exploration Ground Systems program had several months of schedule margin in its work toward a September 2025 launch date at the beginning of the year. But now, the program has allocated all of that margin to technical issues experienced during work on the rocket’s mobile launcher and pad testing.

“Earlier in 2024, the program was reserving that time for technical issues that may arise during testing of the integrated SLS and Orion vehicle or if weather interferes with planned activities, among other things,” the report states. “Officials said it is likely that issues will arise because this is the first time testing many of these systems. Given the lack of margin, if further issues arise during testing or integration, there will likely be delays to the September 2025 Artemis II launch date.”

It’s increasingly unlikely that humans will fly around the Moon next year Read More »

rocket-delivered-to-launch-site-for-first-human-flight-to-the-moon-since-1972

Rocket delivered to launch site for first human flight to the Moon since 1972

artemis, artemis II, human spaceflight, Kennedy Space Center, NASA, Science, SLS core stage, Space, space launch system / /
Rocket delivered to launch site for first human flight to the Moon since 1972

The central piece of NASA’s second Space Launch System rocket arrived at Kennedy Space Center in Florida this week. Agency officials intend to start stacking the towering launcher in the next couple of months for a mission late next year carrying a team of four astronauts around the Moon.

The Artemis II mission, officially scheduled for September 2025, will be the first voyage by humans to the vicinity of the Moon since the last Apollo lunar landing mission in 1972. NASA astronauts Reid Wiseman, Victor Glover, Christina Koch, and Canadian mission specialist Jeremy Hansen will ride the SLS rocket away from Earth, then fly around the far side of the Moon and return home inside NASA’s Orion spacecraft.

“The core is the backbone of SLS, and it’s the backbone of the Artemis mission,” said Matthew Ramsey, NASA’s mission manager for Artemis II. “We’ve been waiting for the core to get here because all the integrated tests and checkouts that we do have to have the core stage. It has the flight avionics that drive the whole system. The boosters are also important, but the core is really the backbone for Artemis. So it’s a big day.”

The core stage rolled off of NASA’s Pegasus barge at Kennedy early Wednesday, following a weeklong ocean voyage from New Orleans, where Boeing builds the rocket under contract to NASA.

Ramsey told Ars that ground teams hope to begin stacking the rocket’s two powerful solid rocket boosters on NASA’s mobile launcher platform in September. Each booster, supplied by Northrop Grumman, is made of five segments with pre-packed solid propellant and a nose cone. All the pieces for the SLS boosters are at Kennedy and ready for stacking, Ramsey said.

The SLS upper stage, built by United Launch Alliance, is also at the Florida launch site. Now, the core stage is at Kennedy. In August or September, NASA plans to deliver the two remaining elements of the SLS rocket to Florida. These are the adapter structures that will connect the core stage to the upper stage, and the upper stage to the Orion spacecraft.

A heavy-duty crane inside the cavernous Vehicle Assembly Building (VAB) will hoist each segment of the SLS boosters into place on the launch platform. Once the boosters are fully stacked, ground teams will lift the 212-foot (65-meter) core stage vertical in the transfer aisle running through the center of the VAB. A crane will then lower the core stage between the boosters. That could happen as soon as December, according to Ramsey.

Then comes the launch vehicle stage adapter, the upper stage, the Orion stage adapter, and finally, the Orion spacecraft itself.

Moving toward operations

NASA’s inspector general reported in 2022 that NASA’s first four Artemis missions will each cost $4.1 billion. Subsequent documents, including a Government Accountability Office report last year, suggest the expendable SLS core stage is responsible for at least a quarter of the cost for each Artemis flight.

The core stage for Artemis II is powered by four hydrogen-fueled RS-25 engines produced by Aerojet Rocketdyne. Two of the reusable engines for Artemis II have flown on the space shuttle, and the other two RS-25s were built in the shuttle era but never flew. Each SLS launch will put the core stage and its engines in the Atlantic Ocean.

Steve Wofford, who manages the stages office for the SLS program at NASA’s Marshall Space Flight Center, told Ars there are “no major configuration differences” between the core stages for Artemis I and Artemis II. The only minor differences involve instrumentation that NASA wanted on Artemis I to measure pressures, accelerations, vibrations, temperatures, and other parameters on the first flight of the Space Launch System.

“We are still working off some flight observations that we made on Artemis I, but no showstoppers,” Wofford said. “On the first article, the test flight, Artemis I, we really loaded it up. That’s a golden opportunity to learn as much as you can about the vehicle and the flight regime, and anchor all your models… As you progress, you need less and less of that. So Core Stage 2 will have less development flight instrumentation than Core Stage 1, and then Core Stage 3 will have less still.”

Rocket delivered to launch site for first human flight to the Moon since 1972 Read More »

nasa-confirms-“independent-review”-of-orion-heat-shield-issue

NASA confirms “independent review” of Orion heat shield issue

artemis, artemis I, artemis II, human spaceflight, NASA, orion, Science, Space, victor glover / /
The Orion spacecraft after splashdown in the Pacific Ocean at the end of the Artemis I mission.

Enlarge / The Orion spacecraft after splashdown in the Pacific Ocean at the end of the Artemis I mission.

NASA has asked a panel of outside experts to review the agency’s investigation into the unexpected loss of material from the heat shield of the Orion spacecraft on a test flight in 2022.

Chunks of charred material cracked and chipped away from Orion’s heat shield during reentry at the end of the 25-day unpiloted Artemis I mission in December 2022. Engineers inspecting the capsule after the flight found more than 100 locations where the stresses of reentry stripped away pieces of the heat shield as temperatures built up to 5,000° Fahrenheit.

This was the most significant discovery on the Artemis I, an unpiloted test flight that took the Orion capsule around the Moon for the first time. The next mission in NASA’s Artemis program, Artemis II, is scheduled for launch late next year on a test flight to send four astronauts around the far side of the Moon.

Another set of eyes

The heat shield, made of a material called Avcoat, is attached to the base of the Orion spacecraft in 186 blocks. Avcoat is designed to ablate, or erode, in a controlled manner during reentry. Instead, fragments fell off the heat shield that left cavities resembling potholes.

Investigators are still looking for the root cause of the heat shield problem. Since the Artemis I mission, engineers conducted sub-scale tests of the Orion heat shield in wind tunnels and high-temperature arcjet facilities. NASA has recreated the phenomenon observed on Artemis I in these ground tests, according to Rachel Kraft, an agency spokesperson.

“The team is currently synthesizing results from a variety of tests and analyses that inform the leading theory for what caused the issues,” said Rachel Kraft, a NASA spokesperson.

Last week, nearly a year and a half after the Artemis I flight, the public got its first look at the condition of the Orion heat shield with post-flight photos released in a report from NASA’s inspector general. Cameras aboard the Orion capsule also recorded pieces of the heat shield breaking off the spacecraft during reentry.

NASA’s inspector general said the char loss issue “creates a risk that the heat shield may not sufficiently protect the capsule’s systems and crew from the extreme heat of reentry on future missions.”

“Those pictures, we’ve seen them since they were taken, but more importantly… we saw it,” said Victor Glover, pilot of the Artemis II mission, in a recent interview with Ars. “More than any picture or report, I’ve seen that heat shield, and that really set the bit for how interested I was in the details.”

NASA confirms “independent review” of Orion heat shield issue Read More »

nasa-still-doesn’t-understand-root-cause-of-orion-heat-shield-issue

NASA still doesn’t understand root cause of Orion heat shield issue

artemis, artemis II, human spaceflight, Lockheed Martin, moon, NASA, orion, Space / /

Flight rationale —

“When we stitch it all together, we’ll either have flight rationale or we won’t.”

–

NASA's Orion spacecraft descends toward the Pacific Ocean on December 11, 2021, at the end of the Artemis I mission.

Enlarge / NASA’s Orion spacecraft descends toward the Pacific Ocean on December 11, 2021, at the end of the Artemis I mission.

NASA

NASA officials declared the Artemis I mission successful in late 2021, and it’s hard to argue with that assessment. The Space Launch System rocket and Orion spacecraft performed nearly flawlessly on an unpiloted flight that took it around the Moon and back to Earth, setting the stage for the Artemis II, the program’s first crew mission.

But one of the things engineers saw on Artemis I that didn’t quite match expectations was an issue with the Orion spacecraft’s heat shield. As the capsule streaked back into Earth’s atmosphere at the end of the mission, the heat shield ablated, or burned off, in a different manner than predicted by computer models.

More of the charred material than expected came off the heat shield during the Artemis I reentry, and the way it came off was somewhat uneven, NASA officials said. Orion’s heat shield is made of a material called Avcoat, which is designed to burn off as the spacecraft plunges into the atmosphere at 25,000 mph (40,000 km per hour). Coming back from the Moon, Orion encountered temperatures up to 5,000° Fahrenheit (2,760° Celsius), hotter than a spacecraft sees when it reenters the atmosphere from low-Earth orbit.

Despite heat shield issue, the Orion spacecraft safely splashed down in the Pacific Ocean. Engineers discovered the uneven charring during post-flight inspections.

No answers yet

Amit Kshatriya, who oversees development for the Artemis missions in NASA’s exploration division, said Friday that the agency is still looking for the root cause of the heat shield issue. Managers want to be sure they understand the cause before proceeding with Artemis II, which will send astronauts Reid Wiseman, Victor Glover, Christina Koch, and Jeremy Hansen on a 10-day flight around the far side of the Moon.

This will be the first time humans fly near the Moon since the last Apollo mission in 1972. In January, NASA announced a delay in the launch of Artemis II from late 2024 until September 2025, largely due to the unresolved investigation into the heat shield issue.

“We are still in the middle of our investigation on the performance of the heat shield from Artemis I,” Kshatriya said Friday in a meeting with a committee of the NASA Advisory Council.

Engineers have performed sub-scale heat shield tests in wind tunnels and arc jet facilities to better understand what led to the uneven charring on Artemis I. “We’re getting close to the final answer in terms of that cause,” Kshatriya said.

NASA officials previously said it is unlikely they will need to make changes to the heat shield already installed on the Orion spacecraft for Artemis II, but haven’t ruled it out. A redesign or modifications to the Orion heat shield on Artemis II would probably delay the mission by at least a year.

Instead, engineers are analyzing all of the possible trajectories the Orion spacecraft could fly when it reenters the atmosphere at the end of the Artemis II mission. On Artemis I, Orion flew a skip reentry profile, where it dipped into the atmosphere, skipped back into space, and then made a final descent into the atmosphere, sort of like a rock skipping across a pond. This profile allows Orion to make more precise splashdowns near recovery teams in the Pacific Ocean and reduces g-forces on the spacecraft and the crew riding inside. It also splits up the heat load on the spacecraft into two phases.

The Apollo missions flew a direct reentry profile. There is also a reentry mode available called a ballistic entry, in which the spacecraft would fly through the atmosphere unguided.

Ground teams at NASA's Kennedy Space Center in Florida moved the Orion spacecraft for the Artemis II mission into an altitude chamber earlier this month.

Enlarge / Ground teams at NASA’s Kennedy Space Center in Florida moved the Orion spacecraft for the Artemis II mission into an altitude chamber earlier this month.

The charred material began flying off the heat shield in the first phase of the skip reentry. Engineers are looking at how the skip reentry profile affected the performance of the Orion heat shield. NASA wants to understand how the Orion heat shield would perform during each of the possible reentry trajectories for Artemis II.

“What we have the analysis teams off doing is saying, ‘OK, independent of what the constraints are going to be, what can we tolerate?” Kshatriya said.

Once officials understand the cause of the heat shield charring, engineers will determine what kind of trajectory Artemis II needs to fly on reentry to minimize risk to the crew. Then, managers will look at building what NASA calls flight rationale. Essentially, this is a process of convincing themselves the spacecraft is safe to fly.

“When we stitch it all together, we’ll either have flight rationale or we won’t,” Kshatriya said.

Assuming NASA approves the flight rationale for Artemis II, there will be additional discussions about how to ensure Orion heat shields are safe to fly on downstream Artemis missions, which will have higher-speed reentry profiles as astronauts return from landings on the Moon.

In the meantime, preparations on the Orion spacecraft for Artemis II continue at NASA’s Kennedy Space Center. The crew and service modules for Artemis II were mated together earlier this year, and the entire Orion spacecraft is now inside a vacuum chamber for environmental testing.

NASA still doesn’t understand root cause of Orion heat shield issue Read More »
